M5Stack ATOM FDD8447L Single-channel PWM Adjustable DC Drive Module Remote Control

M5Stack ATOM FDD8447L Single-channel PWM Adjustable DC Drive Module Remote Control
M5Stack
sku: 1891616
$24.99
Shipping from: China
   Description
Description The ATOM PWM is a single channel PWM regulate DC Driver with built in MOSFET load capacity up to 12V 100W suitable for high power DC motor PWM speed control and industrial heating wire control applications Using ATOM LITE as the core controller built in ESP32 it has a wide PWM dynamic adjustment range eg frequency of 5 kHz duty cycle adjustment range 0 100 resolution up to 13bit and combined with the built in WIFIBluetooth function it can also easily achieve remote control Supports UIFlow graphical programming for easy configuration of signal output and function expansion Product Features Single channel low latency PWM signal outputHigh power MOSFET output capacity 12V 100WReserved 1xGROVE expansion interfaceBuilt in DC DC 12V 5V conversion circuitEasy installation simple operationAll in one design with protective coverDevelopment platform Arduin0 UIFlowSpecification Driver Chip EG27324MOSFET FDD8447LMaximum Output Power 100WInput Voltage Range DC 12V 24VNumber of Drive Channels 1Net Weight 28 9gGross Weight 37 3gProduct Dimensions 24 x 48 x 18mmPackage Size 54 x 54 x 20mmCommon Frequency and Resolution LEDC Clock SourceLEDC Output PWM FrequencyHighest ResolutionAPB CLK 80 MHz 1 kHz1 65536 16 bit APB CLK 80 MHz 5 kHz1 8192 13 bit APB CLK 80 MHz 10 kHz1 4096 12 bit RTC8M CLK 8 MHz 1 kHz1 4096 12 bit RTC8M CLK 8 MHz 8 kHz1 512 9 bit REF TICK 1 MHz 1 kHz1 512 9 bit Applications DC motor controlLight controlHeater controlDC
