M5Stack® Servo2 Servo Driver Module 16 Channels PCA9685 Can Be Stacked And Used Simultaneously ESP32 Development Board

M5Stack® Servo2 Servo Driver Module 16 Channels PCA9685 Can Be Stacked And Used Simultaneously ESP32 Development Board
M5Stack
sku: 1757146
$23.90+4%
$24.99
Shipping from: China
   Description
Description SERVO 2 is an updated servo driver module in the M5Stack stackable module series It uses a PCA9685 16 channel PWM controller to control 16 channel servos at the same time The power input is 6 12V DC and two SY8368AQQC chips are used for voltage reduction The maximum total power output of dual channel is 35W 5V 3 5A 2 and the maximum output power of single channel is 25W 5V 5A When the battery base is used for power supply the maximum output power is 5V 2A The module communicates with the host directly through I2C the default address is 0x40 however the I2C address can be changed 0x40 0x47 through the dial switch This also means that multiple Servo 2 modules can be stacked and used simultaneously There is a power switch on the board to control the power supply of Servo 2 Features 16x actuator drive channel2X power indicatorI2C address adjustableExternal DC power supply input 6 12VDC connector type XT60Include1x Servo2 Module1x XT60 power cable 11 5cm ApplicationsHumanoid robotBioni multi joint robot3 axis steering gear pan tiltSpecification ResourcesParameternet weight28gGross weight60gProduct Size54 2 54 2 13 2mmPackage Size95 65 25mmSchematic click hereRelated Link PCA9685Example 1 Arduin IDETo get the complete code please click here
