M5Stack® RFID RC522 Panel Reader for M5 Face I2C Interface S50 Fudan Cards

Description: FACE-RFID is another FACES kit compatible panel, with the Radio frequency identification on it. Same as RFID units, it is MFRC522-based. The MFRC522 operates in the 13.56MHz frequency band and uses the modulation and demodulation principle to interact with the proximity RF card. This unit can realize the function of the card reading and writing device, to identify and record multiple card information, to encode and authority an RF card. With FACES panel, you can have an upgrade level of RFID device with a more complete and enclosed pattern. Communication Protocol: I2C. Product Features: FACES bottom compatible Interface Serial: UART2 (16/17) MFRC522: Operating frequency: 13.56 MHz I2C data rate: Fast mode: up to 400 Kbit/s; High-speed mode: up to 3400 Kbit/s RC522 Transceiver Buffer: 64 bytes Supported protocol: ISO14443A, MIFARE, and NTAG Operate temperature: -20-85 How long data be saved for > 10 years Reading and writing distance: < 8 cm Program Platform: Arduino, UIFlow(Blockly, Python) Two Le go installation holes Product Size: 58.2mm x 54.2mm x 10mm Product weight: 18.4g Package Included: 1x FACES-RFID panel 1x RFID card 1x Fudan S50 card EasyLoader click to download EasyLoader 1.EasyLoader is a simple and fast program burner. Every product page in EasyLoader provides a product-related case program. It can be burned to the master through simple steps, and a series of function verification can be performed.(Currently EasyLoader is only available for Windows OS) 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. 3.The CP210X (USB driver) needs to be installed before the EasyLoader is burned. Click here to view the driver installation tutorial Schematic: PinMap: M5Core SCL(22) SDA(21) 5V GND FACES RFID SCL SDA 5V GND Document: Datasheet MFRC522 Application: Reader-Tag Security Video
