M5Stack® PRO 13.2 Universal DIY Pro Stack Module 2.54 mm Hole Pitch ProShield for ESP32 Protype Expansion Board

M5Stack® PRO 13.2 Universal DIY Pro Stack Module 2.54 mm Hole Pitch ProShield for ESP32 Protype Expansion Board
M5Stack
sku: 1728641
$8.40+19%
$9.99
Shipping from: China
   Description
Description PRO 13 2 is a universal DIY pro module in the m5stack stack module series with a height of 13 2mm You can easily build your own custom circuits by using this module You can design and build the protype circuit according to your own needs and interact with the M5 Core on the top layer through M BUS There are HY2 0 4P DC power socket VH3 96 and other common openings on the board so it is very simple to use Features Main Hole Size 0 039 1mm CNC Drilled Hole Pitch 0 1 2 54 mm Entire Hole Quantity 169 HolesPackage Included 1x PRO 13 2 board 1x M bus 3x VH 3 96 3P PlugPlug Base 1x HY 2 0 4P Plug Base 1x DC 5V Power outlet 4x M2 5mm Heagon self tapping screw 1x M2 Key 1x stickerSpecification ResourcesParameterNet weight24gGross weight49gProduct Size54 2 54 2 13 2mmPackage Size93 64 20mmMBUS PinMap click to openLEFTRIGHTGNDIO35 ADC1 GNDIO36 ADC2 GNDENIO23 MOSI IO25 DAC0 IO19 MISO IO26 DAC1 IO18 EXT SCK 3V3IO3 U1 RX IO1 U1 TX IO16 U2 RX IO17 U2 TX IO21 I2C SDA IO22 I2C SCL IO2IO5IO12 I2S SCLK IO13IO15 I2S OUT IO0HPOWRIO34HPOWR5VHPOWRBAT
