M5Stack® OLED 1.3-inch Expansion Screen Black/White Display Panel SH1107 Driving Module

M5Stack® OLED 1.3-inch Expansion Screen Black/White Display Panel SH1107 Driving Module
M5Stack
sku: 1863861
$12.68
Shipping from: China
   Description
Description Unit OLED is a 1 3 inch OLED expansion screen unit It adopts SH1107 drive scheme supports black white display and the resolution is 128 64 The driver chip selects the I2C communication interface and the user can mount it to the I2C bus of the existing device when in use which saves IO The back of the screen is integrated with a magnetic design which can easily be fixed on the metal surface by adsorption The OLED screen extension is suitable for being embedded in various instruments or control devices that need to display simple content as a display panel Product Features OLED display panelSH1107 drive schemeDisplay color black whiteI2C communication interface128 64 resolutionViewing angle full viewing angleMagnetic back designSpecification Working current 58mACommunication protocol I2C address 0x3CDisplay size 14 7 29 42 mm Pixel pitch 0 17 0 17 mm Pixel size 0 15 0 15 mm Viewable Full viewOperating temperature 32°F to 104°F 0°C to 40°C Net weight 9 3gGross weight 20gProduct Size 24 56 8mmPackage Size 67 53 12mmCase material Plastic PC Package included 1 x Unit OLED1 x HY2 0 4P CableApplications Information displayPinMap M5Core PORT A GPIO22GPIO215VGNDUnit OLEDSCLSDA5VGNDSchematic Related Link DatasheetSH1107LibraryM5GFX LibraryExample Arduin0
