M5Stack® M5StickC Heart Blood Oxygen Heart Rate Sensor MAX30102 Programmable Smart Medical Module

Description HEART RATE HAT is a blood oxygen heart rate sensor Integrate MAX30102 to provide a complete pulse oximeter and heart rate sensor system solution This is a non pluggable blood oxygen heart rate sensor The sensor uses I2C communication interface internally integrates infrared light emitting diodes optical components and low noise electronic equipment A certain amount of ambient light suppression function can make the measurement results more accurate Instructions After the program is running place your finger on the test area with a stable and fixed pressure Product Features Heart rate monitor and pulse oximeter sensorLED reflective solutionIntegrated protective glass sturdy and durable performanceProgrammable sampling rate and LED currentFast data output capabilityHigh sampling rateStrong elasticity of motion artifactsHigh signal to noise ratioSpecification Sensor model MAX30102Communication protocol I2C 0x57Operating Voltage 3 3VNet weight 5 1gGross weight 12 7gProduct Size 25 24 14mmPackage Size 40 40 30mmCase Material Plastic PC Package included 1 x HEART RATE HAT1 x Double sided tapeApplications Wearable deviceHeart rate blood oxygen collectorSmart MedicalPinMap M5StickCGPIO26GPIO03 3VGNDHEART RATE HATSCLSDA3 3VGNDSchematic Related Link DatasheetMAX30102Example Arduin0Arduin0 Example Code M5StickC Plus with HEART RATE HAT
