M5Stack® Human Body Sensing PIR Motion Sensor Module 2S Delay GPIO Interface

Description: PIR is used to measure infrared (IR) light radiating from objects in its field of view. PIR sensors are commonly called simply "PIR" or sometimes "PID" for "passive infrared detector". The term passive refers to the fact that PIR devices do not radiate energy for detection purposes. They work entirely by detecting infrared radiation emitted by or reflected from objects. This Unit communicates with the M5Core via the GROVE B. Notice: This Unit has 2s delay time. Feature: Detects the distance: 150cm Delay time: 2s Sensing ran ge: < 100 Quiescent current: < 60uA Operating temperature: -20 - 80 C GROVE interface, support UIFlow and Arduino Two Le go installation holes Product Size: 32.2mm x 24.2mm x 20mm Product weight: 4.9g Package Included: 1x PIR unit 1x GROVE Cable Application: Human body Induction Lamp Security Product Automatic Induction Appliance Settings Related Link: Offical Video Forum EasyLoader click to download EasyLoader 1.EasyLoader is a simple and fast program burner, and each product page has a product-related case program for EasyLoader. 2.After downloading the software, double-click to run the application, connect the M5 device to the computer via the data cable, select the port parameters, and click "Burn" to start burning. 3.The CP210X (USB driver) needs to be installed before the EasyLoader is burned. Click here to view the driver installation tutorial Example: 1. for Arduino IDE The code below is incomplete. To get complete code, please click here. #include // initialization M5.begin(); pinMode(36, INPUT);// set pir sensor pin as input // read data int value = digitalRead(36);// read the pin(0: not detectd 1: detected) M5.update();Copy to clipboardErrorCopied 2. UIFlow To get complete code, please click here. Schematic: PinMap: M5Core(GROVE B) GPIO36 GPIO26 5V GND PIR Unit Sensor Pin 5V GND
