M5Stack® ATOM TailBat External Rechargeable Lithium Battery 190mAh Portable Power IP5303 Chip with Indicator Light

 Description TailBat is an external battery accessory designed for M5ATOM If the TailBat module is inserted into the M5ATOM it can directly supply power to the M5ATOM enabling the M5ATOM to be used in mobile applications The TailBat contains a 190mah battery and features a physical button It is controlled by the power management chip IP5303 When the power is turned on the red indicator light will turn on The operation method is the same as that of M5Stack Core Click to turn on the power double click to turn off the power Since the TailBat has been designed simply to add battery power it will not affect the original GROVE Connection mode and USB functionality The built in battery can only be charged through the USB typeC interface not through the grove interface Features Adapted for M5ATOM form factorATOM Matrix PICO ESP32 ID 1645122Plug and playBuilt in rechargeable lithium batteryLED indicatorStick C V M5Camera compatible  More M5Stack Item Click here to openPackage Included 1x TailBatApplication ATOM portable powerSpecification  SpecificationParameterExternal port1x GROVELED1x RED LEDUSB portTypeCBattery capacity190mAhSize55 x 22 x 14mmWeight10gCase materialPlastic PC  Schematic
