M5Stack® ATOM RS-232 M5Atomic TTL to RS232 LevelConverter Full-Duplex Communication Protocol Standard Industrial Control

Description ATOM RS 232 is a TTL RS232 level converter designed for use with the M5Atomic module RS232 is a full duplex communication protocol standard which defines the electrical characteristics of the serial communication system It is a widely used communication protocol in the field of industrial control MAX232 chip is integrated in the module which supports bidirectional conversion between TTL level and RS232 level A DC DC voltage regulator chip is integrated in the ATOM RS485 which can directly convert the 12V voltage of the RS232 hub to 5V to supply power for ATOM Features Compatible ATOM Matrix ATOM Lite Built in DC DC Full duplex communicationPackage Included 1x ATOM RS 232 1x ATOM Lite 1x Key 1x M2 8mm Heagon socket cup head machine screw 1x 18cm TYPE C CableApplications RS232 Communication Industrial control nodeSpecification SpecificationParameterExternal portVH 3 96 4Plevel conversion ICMAX232DC DCA0Z1282CINet weight26gGross weight36gProduct Size24 48 18mmPackage Size54 54 20mmCase MaterialPlastic PC EasyLoader Click to downloadEasyLoader is a concise and fast program writer which has a built in program related to the product It can be burned to the main control by simple steps to perform a series of function verification Please install the corresponding driver according to the device type M5Core host Please click here to view the CP210X driver installation tutorial M5StickC V T ATOM series can be used without driver Related Link MAX23
