M5Stack® ATOM Matrix PICO ESP32 Development Board Kit IMU Sensor Python

M5Stack® ATOM Matrix PICO ESP32 Development Board Kit IMU Sensor Python
M5Stack
sku: 1645122
$20.50+12%
$22.99
Shipping from: China
   Description
Description ATOM Matrix is the most compact development board in the M5Stack development kit series yet with a size of only 24 24mm It provides more GPIO pins and is very suitable for handy and miniature embedded device development The main control adopts the ESP32 PICO D4 chip which comes integrated with Wi Fi and Bluetooth technologies and has 4MB of integrated SPI flash memory The Atom board provides an Infra Red LED along with the 5 5 RGB LED matrix on the panel a built in IMU sensor MPU6886 and a PH2 0 interface A general purpose programmable button is provied below the RGB Led matrix to enable users to add input support to their various projects The on board USB interface Type C enables rapid program uploading and execution One M2 screw hole is provided on the back for mounting the board NOTE We have set the brightness of RGB LED limited to 20 Pls DO NOT set it higher to avoid damaging the LED and acrylic screen Product Features USB Type CESP32 PICO based4 MByte flash1 Programmable button5 5 RGB LED matrix panelInfra red LEDReset button2 4G SMD Antenna Proant 440MPU6886 Inertial Sensor6 GPIO Dupont Pins GROVE 4Pin PH2 0 interfaceProgram Platform for Arduino UIFlowProduct Size 24 24 14mmProduct weight 1gESP32 Features 240 MHz dual core Tensilica LX6 microcontroller with 600 DMIPSIntegrated 520 KB SRAMIntegrated 802 11b g n HT40 Wi Fi transceiver baseband stack and LWIPIntegrated dual mode Bluetooth classic and BLE Hall sensor10x capactive t
