M5Stack® ATOM MATE DIY Expansion Kit Adapter Board for Adapting M5StickC Hat Series Flexible Installation

Description ATOM MATE is a DIY expansion kit specially designed for the M5ATOM family The kit contains 3 kinds of accessories AtomPin is a pin adapter board that can expand the bottom pins of the M5Atom from all sides making it easier to build circuits on the breadboard With a special bracket you can easily attach M5Atom without affecting the use of the pins AtomHat is an adapter board for adapting the M5StickC Hat series of products for use with the M5Atom If you already have some HAT accessories you can directly use the AtomHat adapter to reuse them with M5Atom There is a cross shaped hole on the bottom which can be connected to Leigo allowing for easy mounting onto Leigo projects Note Please check the Hat pins before using AtomHat you may need to modify the program pin number when using PIR HAT with AtomHat it is necessary to set the 33 pin as an internal pull upFeatures Compatible with Atom Matrix Atom Lite Multiple DIY methods Flexible installation Adapt to HAT bread boardPackage Included 1x AtomPin frame 1x AtomPin board 1x AtomHat 1x AtomMount 5x 5Pin 1x 4Pin 1x M2 6 Heagon socket cup head machine screw 1x M2 8 Heagon socket cup head machine screw 1x keyApplications Experimental circuit construction Use with building blocks HAT transferSpecification SpecificationParameterNet weight11gGross weight22gProduct SizeAtomHAT 24 24 8mm AtomMount 24 24 8mm AtomPin 24 38 8mmPackage dimensions50 50 21mmCase materialPlastic PC PinMap HATGND5VG26G3
