Link Electronics VSW-824 8x1 S-VHS Matrix Vertical Interval Video Switcher

The VSW-824 Is a wide band-width vertical Interval switcher designed for S-VHS inputs. It's eight terminated inputs and single output allow the user to efficiently and economically route or delegate multiple S-VHS video signals. Packaged in a 19" rack mountable cabinet, the VSW-824 features 8 S-VHS inputs. High-quality push buttons and LED digital readout of audio and video channel selection make this unit an ideal solution. Audio and video breakaway is front panel controlled. Serial control is provided through a DSub connector. Remote control is provided through a RJ-11 connector. Serial control characteristics are RS-232, RS-422 and RS-485. Switching is accomplished during the vertical interval by using the vertical sync derived from the video at the output stage of the VSW-824 video switcher. The VSW-824 is a video-only switcher with both sets of LED digital readouts for the audio and video selected. When connected with the PAF-823 audio follow unit, the VSW-824 selects the video and it's Companion audio. A three position front panel switch selects audio follow, audio breakaway and video break-away. There is one output of the selected video on the rear panel.
