Lichee Pi Nano Cross-Border Core Board ARM 926EJS 32MB DDR Development Board Mini PC

Description:Using F1C100s as the main chip of lichee pi Nano, Arm9 architecture, 16KB D-Cache, 32KB I-Cache, support boot from SPI Flash or TF card, support USB OTG loading update.Hardware parameter CPU: All-in-one F1C100s, ARM 926EJS, up to 900MHz RAM: Integrated 32MB DDRStorage:Reserved SOP8 SPI Flash pad (this version is no Flash)Onboard TF card holder, can be started by TF. The tf wifi module can be added.Display:Universal 40P RGB LCD FPC BlockCan be directly inserted into the common 40P 4.3/5/7 inch screen (onboard backlight driver), through the adapter board can be inserted 50P 7/9 inch screenSupport 272x480, 480x800, 1024x600 and other resolutionsOn-board resistive touch screen chip supporting resistive screenSupport 720P video outputSupport video stream decoding such as H.264 / MPEGCommunication Interface:SDIO, can be used with the supporting SDIO WiFi moduleSPI x2TWI x3UART x3OTG USB x1TV out x 1, TV in x 2Other interface:PWM x2LRADC x1Speakerx2 + Mic x1Electrical characteristics:Micro USB 5V power supply; 2.54mm pin 3.3V~5V power supply; 1.27mm stamp hole power supplyOutput 3.3V, selectable input RTC voltage900MHz linux no-load operating current 54mA, with screen operating current ~250mAStorage temperature -40~125°C, operating temperature -20~70°CSupport:CSI CameraFull HD Video Engine(H.264,H.263,JPEG/MJPEG,etc.)RGB LCD InterfaceCVBS Input/OutputAudio CodecI2S/PCMSD/eMMcPackage Included:1x Lichee pi Nano board1x Adapter
