Lichee Nano Motherboard F1c100s Development Board Linux Programming Learning

Electrical characteristics Input 5V through the micro USB port input 3 3 to 5V through the pin Output 3 3V optional input RTC voltage Power consumption 54mA idle when using Linux 250mA with display Storage temperature 40 125°C Operation 20 to 70°C Sipeed Lichee Nano with Flash Linux Development Dev Board 16M Flash VersionIOT Internet of Things Lichee Nano is a SD card sized Linux development board powered by the Allwinner F1C100s ARM9 processor Lichee Nano 22CPU Allwinner F1C100s ARM 926EJS processor up to 900MHzMemory and storage 32MB DDR integrated into SoC 16MB SPI Flash Onboard TF slot can be booted from TF card Display 40pin RGB LCD FPC connector supports 272 480 480 800 1024 600 and other resolution resistive displays and capacitive displays through the adapter board Support 720P video output support video stream decoding such as H 264 MPEGCommunication Interface SDIO for WiFi module SPI x2 TWI x3 UART x3 OTG USB x1 TV outputOther interface PWM x2 LRADC x1 Headphone output x2 Mic x1 Software and development environment Support for 3 10 BSP linuxSupport 4 19 main line linuxSupport xboot bare metal development environmentSupport RT ThreadTarget application scenario IoT applications use more complex communication interfaces and protocolsThe application of human computer interaction interface requires more beautiful and complex logicApplication scenarios that require more operations as opposed to regular MCUs Need to
