Latest WiFi Telemetry Serial Port Module for APM Pixhawk Flight Controller

Latest WiFi Telemetry Serial Port Module for APM Pixhawk Flight Controller
PIXHAWK
sku: 1054831
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$9.29
Shipping from: China
   Description
Latest WiFi Telemetry Serial Port Module for APM Pixhawk Flight Controller Description: Item Name: WiFi Telemetry WIFI 802.11b TCP server port 2323 Server:IP 192.168.4.1 AP Mode Max. Power: 20dbm Wifi Antenna Gain: 3db Working Voltage: 5V Max. Current: 200mAh Serial Port Protocol:TTL Serial Baud Rate: 57600bps,8,n,1 Features: Plug and play Plug to Tele port on FC Support mobile ground station Support multi FC Support Arduino development board Use: Search "wifi_tele" enter code:"12345678",enter ip "192.168.4.1" and port "2323". Arduino/Stm32/Stc Developmeng Board Use: Whatever SCM you use, it supports serial communication. Please set the main baud rate to "57600bps 8,n,1," connect with WiFi telemetry tx-------------------rx rx-------------------tx 5v------------------5v gnd----------------gnd Then power on it, search the wifi_tele on your mobile or computer, connect it, enter the code: "12345678". (The computer can use NC software, the mobile can use TCP software) And run "192.168.4.1 2323" on computer. No matter what has entered on computer,the SCM will receive it. FAQ: The distance of default antenna is about 50m, you can use te pannel antenna for longer distance Package Included: 1 x Module
