LM-PCS01 Pro CVBS/AV to SD/HD/3G SDI Converter

LM-PSC01 Professional SDI to CVBS/AV Converter is apply to 3G/HD/SD SDI Signal Conversion Converter, integrates FRCS ( Frames Rate Conversion System), SDI Receivers and CVBS Encoder, can convert the 3G/HD/SD SDI signal to composite Video CVBS. At the same time, LM-PSC01 SDI to CVBS/AV Converter supports de-embedded audio from 3G/HD/SD SDI signal, output to the analog ports.
Features
Supports 3G/HD/SD SDI Signal Input.
Supports 3G/HD/SD SDI Signal Looping Output.
Supports 1080p/1080i/720p/480i/576i Video format.
Supports 1080PSF/ 720P 30/25/24Hz.
SD CVBS output (Supports PAL/NTSC).
Supports Down-Conversion function.
Down-Conversion have three mode (Left/Right Cut, T/B Black, Point to Point Output) can be chosen.
Adaptively SDI Input signal.
De-embedded Audio from SDI Input signal.
Supports Analog stereo audio output.
SDI Looping out and synchronous CVBS output.
Color Bar output.
Specifications
Name CVBS to SDI HD Video Converter
Model No. LM-PCS01
CVBS Video Input Signal Standard CVBS Signal; SMPTE 27M; Connecter BNC; Signal Amplitude 800mv ±10% ( 75 Ω); Impedance 75Ω
Analog Audio Input Input Signal Analog Stereo Audio; Digital Sampling 48K; Impedance 16Ω; Connector Earphones
SDI Video Output Output Signal SD/HD/3G SDI; Connector BNC ( IEC169-8 Standard ); Signal Amplitude 800mv ±10%; Impedance 75Ω
Power Supply DC 5-12V;
Power < 2W
Control DIP Switch
Operating Temperature Range 0-50℃
Storage Temperature Range -20 to 75℃
Operating Humidity Range 20-70%RH
Storage Humidity Range 0-90%RH
Weight 230g
Product Size 15cm x 11cm x 3cm
Package Size 22cm x 17cm x 5cm
What's in the box?
1 x Main unit
1 x DC 5V Power Adapter
1 x User Manual
