LM-103TRS 300M VGA Audio UTP Extender CAT5/UTP Adjustable

Features
The 300M VGA Extender transmits VGA video up to 1000 feet (300m) away from a computer using CAT5/5e/6 cable.
Ideal solution for digital signage applications.
Supports local and remote VGA monitors.
Supports resolutions to 1920x1440.
Sharpest and clearest VGA quality over CAT5/UTP-STP cable of any manufacturer.
Built-in lightning and ESD surge protection.
Available with optional stereo audio.
Use in-house CAT5/5e/6 phone wiring to locate a monitor remotely.
Optional VESA mounting bracket is available for mounting the remote unit to the back of a flat panel monitor.
Specifications
Name VGA Audio UTP Extender CAT5/UTP
Model LM-103TRS
Connector standard HDB15, RJ45
Input connector HD15PIN(VGA)
Output connector HD15PIN(VGA)
Local output HD15PIN(VGA)
Bandwidth 680MHZ@-3db
Input level range 0.5-2.0Vp-p
Input level error less than 3Mv
Input impedance 75 ohm
Output impedance 75 ohm
SNR 6db
Video standard VGA, SVGA, XGA, SXGA, UXGA, LCD
Cable standard cat5, cat5e, cat6 UTP cable and cat5e is suggested
Power adapter DC 12V/1A
Receiver Size 95L x 97W x 28H mm
Sender Size 64L x 45W x 23H mm
Weight 600g
Package Contents
1 x VGA Extender Receiver
1 x VGA Extender Sender
1 x 12V Power Adapter
1 x User Manual
