LINK-MI LM-EX02 50m HDMI Extender Repeater Via HDMI Cable
Description
Features
Extend via HDMI cable,the distance up to 50 meters.
Compact size.
No need outside power supply (The power input is optional).
No system control required.
Support 3D video formats.
CEC Pass-Through.
Signaling rates up to 2.25Gbps in support of UXGA and 1080P display.
40dB receiver equalization.
Specifications
Brand LINK-MI
Model No. LM-EX02
Material PE Plastic
Color White
Interface HDMI
Application Extend HDMI Signal up to 50m over HDMI cable
Operating Temperature Range -5 to +35 Degree Celsius ( +23 to +95 Degree Fahrenheit )
Operating Humidity Range 5 to 90%RH ( No Condensation )
Input Video Signal 0.5-1.0 Volts P-P
Signal Rate Up to 2.25Gbps
Compatible Computer Signal VGA, SVGA, SXGA, XGA, UXGA
Audio Format DTS-HD Master Audio, Dolby True-HD etc.
Transmission Distance0 to 50m Over HDMI Cable, 26AWG STP ( Shielded-Twisted Pair );0 to 36m Over HDMI Cable, 28AWG STP ( Shielded-Twisted Pair );0 to 30m Over HDMI Cable, 30AWG STP ( Shielded-Twisted Pair )
Auto Equalization Up to 40dB at 825MHz ( 1.65Gbps )
Power Consumption 0.7 Watts ( Max. )
Dimension ( LWH ) 52 x 36 x 19mm
Weight 30g
Extend via HDMI cable,the distance up to 50 meters.
Compact size.
No need outside power supply (The power input is optional).
No system control required.
Support 3D video formats.
CEC Pass-Through.
Signaling rates up to 2.25Gbps in support of UXGA and 1080P display.
40dB receiver equalization.
Specifications
Brand LINK-MI
Model No. LM-EX02
Material PE Plastic
Color White
Interface HDMI
Application Extend HDMI Signal up to 50m over HDMI cable
Operating Temperature Range -5 to +35 Degree Celsius ( +23 to +95 Degree Fahrenheit )
Operating Humidity Range 5 to 90%RH ( No Condensation )
Input Video Signal 0.5-1.0 Volts P-P
Signal Rate Up to 2.25Gbps
Compatible Computer Signal VGA, SVGA, SXGA, XGA, UXGA
Audio Format DTS-HD Master Audio, Dolby True-HD etc.
Transmission Distance0 to 50m Over HDMI Cable, 26AWG STP ( Shielded-Twisted Pair );0 to 36m Over HDMI Cable, 28AWG STP ( Shielded-Twisted Pair );0 to 30m Over HDMI Cable, 30AWG STP ( Shielded-Twisted Pair )
Auto Equalization Up to 40dB at 825MHz ( 1.65Gbps )
Power Consumption 0.7 Watts ( Max. )
Dimension ( LWH ) 52 x 36 x 19mm
Weight 30g
