LINK-MI LM-EW60-3DIR 60m Single Cat5e6 HDMI Wall Plate Extender

Features
Each set includes one transmitter and one receiver.
Following North American Wall Plate Standard.
Modular design.
Using single UTP cable ( cat5e/6 ) to substitute HDMI cable to achieve long distance transmission, the UTP cable follows the standard of IEEE-568B.
Transmission distance reaches up to 60 meters under the video format of 1080p.
Auto-adjustment of feedback, equalization and amplify.
Signaling rates up to 2.25Gbits in support of 1080p display.
With Infrared Control signal passing through function.
Supports 3D Video format.
Connecting and Operating
Connect the HDMI input source (such as HD-DVD / PS3 / STB etc) into TX.
Connect the two CAT-5E or CAT6 cables to both the outputs of TX and inputs of RX. Please pay attention to the right connection of the two cables, CAT5e/6-1＞CAT5e/6-1 (The cables must follow the standard of EIA/TIA 568B).
Connect the HDMI output (such as HD-LCD / HD-DLP) into RX.
Connect the IR TX UNIT into TX; Connect the IR RX UNIT into the RX.
Specifications
Brand LINK-MI
Model No. LM-EW60
Material PE Plastic
Color White
Interface HDMI
Application Extend HDMI Signal up to 60m over single UTP cable
Operating Temperature Range -5 to +35℃ ( +23 to +95℉ )
Operating Humidity Range 5 to 90%RH ( No Condensation )
Input Video Signal 0.5-1.0 Volts P-P
Input DDC Signal 5 Volts P-P ( TTL )
Video Format DTV/HDTV: 480i/576i/480p/576p/720p/1080i/1080p
Video Output HDMI HDCP 1.1
Audio Format DTS-HD Master Audio, Dolby True-HD etc.
Transmission Distance 1080p 8-bit 30m (Max. ); 1080p 12 bit 25m ( Max. ) Over Cat5e/6/24AWG/Solid ( Recommend to use 23AWG Cat6 Cable )
Wavelength 940nm
Frequency 38KHz
Power Consumption 3 Watts ( Max. )
Dimension ( L x W x H ) 115 x 70 x 35mm
Packing Contents
1 x Main Unit. HDMI Wall Plate Extender Transmitter & Receiver
2 x DC 5V 1A Power Supply
1 x IR TX Unit ( IR Emitter Cable )
1 x IR RX Unit ( IR Receiver Cable )
1 x Operating Instructions
