LILYGO® TTGO Camera Module OV2640 2 Megapixel Adapter Support YUV RGB JPEG For T-Camera Plus ESP32-DOWDQ6 8MB SPRAM

Feature: Camera: OV2640 Camera Resolution: 2Megapixel Type: Normal / Lengthened Normal / Fisheye lens / Lengthened fisheye lens (Optional) Size: 21.77 x 12.61 x 4.28mm / 74.91 x 12.61 x 4.28mm Camera Seat: 8.54mm 24pin Array Size UXGA 1600 x 1200 Power Supply Core 1.2VDC + 5% Analog 2.5 ~ 3.0VDC I/O 1.7V to 3.3V Power Requirements Active 125 mW (for 15 fps, UXGA YUV mode) 140 mW (for 15 fps, UXGA compressed mode) Standby 600 A Temperature Operation -30C to 70C Range Stable Image 0C to 50C Output Formats (8-bit) YUV(422/420)/YCbCr422 RGB565/555 8-bit compressed data 8-/10-bit Raw RGB data Lens Size 1/4" Chief Ray Angle 25 non-linear Maximum UXGA/SXGA 15 fps Image SVGA 30 fps Transfer Rate CIF 60 fps Sensitivity 0.6 V/Lux-sec S/N Ratio 40 dB Dynamic Range 50 dB Scan Mode Progressive Maximum Exposure Interval 1247 x tROW Gamma Correction Programmable Pixel Size 2.2 m x 2.2 m Dark Current 15 mV/s at 60C Well Capacity 12 Ke Fixed Pattern Noise
