LHCER DDCSV3.1 Off-Line Controller ARM9 Chip Printing Machinery For CNC Machine Tools

Features: Upgrade algorithm support soft interpolation fixed arc interpolation of the old version. 16 opto isolated digital inputs 3 opto isolated digital outputs. 3 axle motor Control.Differential Pulse and direction output signal maximum.500Khz per axle. ARM9 main control chip FPGA core algorithm chip. 5 inches TFT screen resolution ratio: 480x272 17 operation keys. Analog spindle control 0-10V spindle control (can be modified as PWM output). 24VDC power input minimum Current is 0.5A. USB flash disk support for G code file input no size limited of the G-code file. 1GB internal memory and support standard MPG. Jog function for each axle (continuous step defined distance). Support the operation of quickly specify the running position and Power Cut recovery. Data is automatically saved. Support the origin and Limit share the same Input ports.The controller only support NPN type limited switch. Drive output type strong anti-interference ability long-distance transmission. Applications: CNC machine tools printing machinery and other zero correction and signal segmentation. Specification: Handwheel Working Voltage:5V Handwheel Three Output:Voltage Single-Ended Differential Handwheel Pulse Output:100PPR Package List: 1 x Controller 1 x Flash Disk 1 x Terminal 1 x Connection Cord 1 x Installation Screw 1 x Handwheel 1 x Handwheel Hook Note: Please note that the new type and old type of this product will be sent randomly and make sure you will not mind before ordering.
