LF-R800U 2.4GHz 300Mbps Outdoor Wireless Bridge CPE

As a long range outdoor wireless device, the LF-R800U is designed to provide a WISP connection and long distance wireless networking solution. It operates seamlessly in the 2.4GHz frequency spectrum and provides wireless data transfer rates of up to 300Mbps. The device also features up to 500mw wireless transmission power and has a built-in 14dBi antenna which provides a cost effective way to pick up and maintain a stable signal for a wireless network connection ranging multiple kilometers.
Features
Outdoor weatherproof protection design, Two Ethernet Port.
600MHz MTK7620A RF Chipset, 802.11b/g/n Support.
64MB SDRAM + 8MB Flash Build-in for Higher Performance.
Gateway / Repeater / AP Client operation modes.
24V Passive PoE supports up to 70 meter (200 feet) deployment.
14dBi directional MIMO antenna to build long distance Wi-Fi connection.
Central AP Control Management Software Support (AP Mode Only).
Specifications
Wireless
Standards IEEE 802.11n, IEEE 802.11g, IEEE 802.11b
Data Rate 300Mbps
Frequency Band 2.4~2.4835GHz
Wireless Transmit Power 11n MCS7:26±1dBm 11g 54Mbps:26±1dBm 11b 11Mbps:27±1dBm
Receive Sensitivity 11N MCS0@-83dBm ; MCS7@-65dBm 11G 54Mbps@-82dBm ; 6Mbps@-95dBm 11B 11Mbps@-85dBm ; 1Mbps@-95dBm
Operation Mode Gateway, Repeater(Extender), AP(access point)
Wireless Security 64/128-bit WEP, WPA/WPA2, WPA /WPA2-Personal (TKIP/AES)
System Requirements Windows 7/Vista/XP/2000,Mac OS®, Linux or Android OS, IOS
Hardware
Interfaces 2 x RJ-45 for 10/100 Mbps(POE), 1 x Power DC Jack
MCU MTK7620A
SDRAM&FLASH 64MB+8MB
Button 1 x Reset button(Reset & Factory Defaults)
LED Indicator WiFi, Power, System
Antenna 14dBi Directional Antenna
Power Supply 24V PoE/12V1A; 110V/220V
Software
Wireless Function Distance Control (802.1x Ack timeout), Multiple SSID (4 SSID)
Security WEP Encryption-64/128/152 bit WPA/WPA2 Personal (WPA-PSK using TKIP or AES) WPA/WPA2 Enterprise (WPA-EAP using TKIP) Hide SSID, MAC/IP Address &URL filtering Wireless STA (Client) connected list
DHCP DHCP Server, DHCP Client
Network Port Mapping, DMZ Host, Statics Routing, DDNS,UPNP
Management Firmware Upgrade and backup, factory Reset, Restart, WEB management, log management, the PING tool
Product Size 26 x 8 x 3 cm
Product Weight 400g
Package Size 33 x 9 x 10 cm
Package Weight 700g
