LCD8000-43T 4.3 Inch LCD Sreen + BB VIEW Expansion Board

LCD8000-43T 4.3 Inch LCD Sreen + BB VIEW Expansion Board For Embest BeagleBone Specification: LCD8000-43T 4.3 Inch LCD Sreen Screen Size: 4.3 Inch Module Dimensions (W x H): 120.2mm x 80.0mm Visible Area (W x H):101.1mm x 67.5mm Resolution: 480 x 272 Operating Temperature: -10 - 60C Storage Temperature: -20 - 70C Power Supply and Consumption: 5V input power. Typical consumption 1W. Touch-Screen: 4-wire resistive touch-screen BB VIEW Expansion Board Supports Embest's LCD Module such as LCD8000-43T and LCD8000-70T. Can be used on Beagleong black and BeagleBone The design that extends the I/O interfaces of BB-Black Replica allows users have access to rest of I/O interfaces while using LCD display function. Powered byBeagleBone Black or BeagleBone directly without need of external power supply. Mounting holes ensure a reliable assembly of BB VIEW and BeagleBone Black by using brass tube plugs and nuts. The LCD interface definitions are as same as that of Embest's single board computers such as Devkit8000 and SBC8600, which means it is fully compatible with the hardware design of these single board computers. Note: Currently 4.3-inch and 7-inch LCD modules have been proved on BB-Black Replica. The support to VGA8000,LVDS8000 plus will be covered later. Technical Documentation: http://www.embest-tech.com/product/expansion-modules-accessories/bb-view.html Package included: 1 x LCD8000-43T 4.3 Inch LCD Sreen 1 x BB VIEW Expansion Board
