LCD Screen Accelerometer LCD Display Moudle Development Board Raspberry Pi PICO RP2040 LCD Module

Label:Yes Type:RP2040 Development Board Packing List:1Pc Development Board Model:RP2040 Color:as shown Size:as shown Overview: RP2404-LCD-1.28 is a high-performance microcontroller development board. Under the condition of small board type, On-board 1.28inch LCD, lithium battery charging chip, six-axis sensor (three-axis acceleration and three-axis gyroscope) and other peripherals, All GPIO and Debug interfaces are introduced, which is convenient for users to develop and embedded in products. Specifications RP2040 microcontroller chip designed by Raspberry Pi Dual-core Arm Cortex M0+ processor, flexible clock running up to 133 MHz 264KB of SRAM, and 2MB of on-board Flash memory USB-C connector, keeps it up to date, easier to use On board a 1.28-inch LCD screen All GPIO s (30 in total, but some pins have been connected to the internal bu circuit, so please pay attention when multiplexing. Please refer to the details) are led out by 1.27-pitch bus bar. USB 1.1 with device and host support Low-power sleep and dormant modes Drag-and-drop programming using mass storage over USB 2 × SPI, 2 × I2C, 2 × UART, 4 × 12-bit ADC, 16 × controllable PWM channels Accurate clock and timer on-chip Temperature sensor Accelerated floating-point libraries on-chip 8 × Programmable I/O (PIO) state machines for custom peripheral support On-board lithium battery charging and discharging interface is beneficial for RP2040-LCD-1.28 to be used in some mobile scenes.
