LC100-A High Precision Capacitor Multimeter Test Instruments

LC100-A joined the the capacitor 1uF-100mF measurement the following figure is a measure of six capacitor 4700uF capacitor in parallel measured 28.7mF equivalent to a capacitor 4.78mF 28.7mF capacity is beyond ordinary capacitor the range of the table the instrument test range directly to 100 mF! in the small capacitance small inductors and inductive test LC100-A and LC100-S is the the following LC100-S as an example: The following is the example of measuring small capacitance can be seen from the the resolution has been reached 0.01pF you must pay attention to the impact of the test clip to maintain test clip without access capacitance normalized 0 and then as much as possible to maintain the relative position of the test clip into the capacitor unchanged this is the for testing small inductance. The following pictures are examples of measuring small inductance see from the around 4 turn hollow coil wire test results 0.058uH this result is equivalent to 58nH for the 6243 class of instrument is absolutely undetectable inductive The advantage of this is also the instrument. The third is a measure of a 0.22uF safety capacitor the figures are very stable measurement results here to give you a if you the test results beating very this capacitor stability is poor or poor high-frequency characteristics and the good capacitive display results very stable. Measurement accuracy: 1% Capacitance measuring range: 0.01pF-10uF Minimum resolution: 0.01pF Inductance Range: 0.001uH-100mH Minimum resolution: 0.001uH inductance measurement range: 0.001mH-100H Minimum resolution: 0.001mH capacitance measuring range: 1uF-100mF Minimum resolution: 0.01uF Test frequency: capacitors inductors file about 500kHz inductance of about 500Hz Can display current test frequency value Effective display digits: 4 Display: 1602 LCD supply: miniUSB interface to take or 5V supply SMD soldering components stable and reliable Colour: as shown Material: ABS Size: 8x5x3CM Package Contents: 1 * LC100-A inductor-capacitor Table 1 * Only the above package content other products are not included. Note: Light and different displays may the color of the item in the a little different from the real thing. The measurement allowed error is +/- 1-3cm.
