LA1010 USB Logic Analyzer 100M Max Sample Rate 16 Channel MCU/ARM/FPGA Debug Tool Oscilloscopes

Description LA1010 is a logic analyzer product with high cost performance It has 16 input channels and the sample rate is up to 100MHz Along with the PC software KingstVIS 16 channels of digital signal could be sampled at the same time and then they could beconverted to digital waveform and displayed on the PC screen The signal could be analyzed with many standard protocols to get more straightforward communication data It helps a lot in testingand analyzing digital system MCU ARM FPGA etc developing and debugging several communication programs or monitoring and recording some digital signals for a long time Software and user manual http www kingst org download fl vis zipFeatures Portable and lightweightMax sampling rate 100M 3channels 50M 6channels 32M 9channels 16M 16channelsLarge sampling depth and support compressionThe built in PWM generatorCompatible USB2 0 3 0 interfacePowerful software and easy to useSupport online upgrade automatically Specifications Input channels number 16Max sampling rate 100MMeasurement bandwidth 20MMin pulse width can be captured 20nsMax sampling depth 10G channelInput voltage range 50V 50VInput impedance 220K 12pFAdjustable threshold voltage 4V 4V step 0 01VPWM channels number 2PWM frequency range 0 1 10MHzPWM frequency adjust step 10nsPWM pulse width adjust step 10nsPWM output voltage 3 3VPWM output impedance 50Standby current 100mAMax operating current 150mADimensions 95mm 55mm 23mmSu
