Kramer Electronics VS-84UHD 8x4 4K60 4:2:0 Matrix Switcher

VS-84UHD is a high-quality 8x4 matrix switcher for 4K at 60Hz (4:2:0) HDMI signals and embedded audio. It reclocks and equalizes the signals and can route any one of eight HDMI, HDCP-compliant sources (selectable) to any or all outputs simultaneously. VS-84UHD offers a flexible audio scheme where any HDMI digital audio input can be routed to any HDMI digital audio output in addition to ARC support to produce an equivalent 12x8 audio matrix. Max. Data Rate 8.91Gbps data rate (2.97Gbps per graphics channel). Max. Resolution 4K at 60Hz (4:2:0). Independent 12x8 Audio Matrix With 8 embedded digital inputs + 4 ARC inputs and 4 embedded digital outputs + 4 ARC outputs. Memory Locations 12 presets for quick access to common configurations. Automatic Input Selection Based on priority selection or last connected input. HDMI Support Deep Color, 3D, ARC, up to 7.1 uncompressed audio channels. Kramer reKlocking and Equalization Technology Rebuilds the digital signal to travel longer distances. Lock Button To prevent tampering. Firmware Upgrade Via mini USB, Ethernet or the RS-232 port. Control Options RS-232 serial commands transmitted by a PC, touch screen system or other serial controller, Ethernet port via LAN, embedded Web pages via LAN for configuration and control. Size Standard 19" (1U). Rack "ears" included.
