Kramer Electronics VS-3232DN 4x4 to 32x32 Modular Digital Matrix Switcher

VS-3232DN is a high-performance 4x4 to 32x32 modular matrix switcher chassis for AV signals. The unit is a multi-format digital switcher, populated from 4x4 to 32x32 in increments of four inputs and/or four outputs. The chassis includes optional dual, redundant power supplies, a control module and a test module that can monitor and test any input and output in the matrix. VS-3232DN supports a wide variety of input and output cards for different AV signals. Kramer Core FLEXIBLE INFRASTRUCTURE CONVERSION! Copper, Fiber or Twisted Pair all can be used at the same time, according to input/output module selection. The matrix receives digital signals from compatible Kramer transmitters, automatically converts between available infrastructure options and sends the signals to compatible Kramer receivers. Kramer Core solution is the ultimate in versatility! Max. Data Rate 10.2Gbps (3.4Gbps per graphics channel) when using compatible cards. HDCP Compliant With DVI (HDCP), HDMI, F670, HDBaseT, DGKat modules. Cables For optimum range and performance, use recommended Kramer cables. Kramer Equalization & re-Klocking Technology Rebuilds the digital signal to travel longer distances. Optional Fast Switching Support For fraction of a second switching. Modular & Easily Configurable Platform Input or output module types can be mixed and added in increments of 4 from 4x4 up to 32x32. Flexible Configuration To disable HDCP support and convert between HDMI and DVI. Default EDID For each input. EDID Capture Copies and stores the EDID from a display device. Take Button Executes multiple switches all at once. Memory Locations Stores multiple switches as presets to be recalled and executed as needed. Test Pattern Module With 4 output resolutions for troubleshooting video problems and additional monitor port with audio embedding and de-embedding. Redundant Power Supply Hot-swappable, 2 separate units with independent power inlets. Flexible Control Options Front panel, IR remote (included), RS-232 (K-Router Windows-based software is included), Ethernet. Worldwide Power Supply 100-240V AC.
