K212 Switch Power Supply Fingerprint Access Control Control Board Door System

K212 Switch Power Supply Fingerprint Access Control Control Board Door System
sku: 1694341
ACCORDING TO OUR RECORDS THIS PRODUCT IS NOT AVAILABLE NOW
$12.99
Shipping from: China
   Description
Manual Click here to openSpecifications Power supply DC8 30V Stand by mode current 40mA Fingerprint capacity 200 Interface output of motor ±DC5V 300mA Interface output of relay 3AK202 is designed for low power consumption the power supply is DC12V the relay time can be adjusted by rotating the button relay time 0 5 13 seconds It is very easy to register fingerprint just need to press SET button to register fingerprint and long press SET button to back to factory default Interface Usage P1 Power supply Input voltage DC8 30V Input current 0 3A P2 Relay outputP3 Active Signal of open door Voltage DC12V Input P4 Fingerprint module Input P5 Micro motor Output P6 Button for opening door closing signal Input Adjustable resistance Setting closing time for relayOperation Instructions 1 System on working state indicator light LED flash slowly 2 Press SET button system in register state and indicator light flash fastly 3 Fingerprint can be registered continuously when system in register state if no need for adding fingerprint more exit after waiting 5 seconds or by press SET button 4 When back to factory default press RESET button until hear Di release the button hearing Di long beep means operation successful 5 Fingerprint verified or the button for opening door closed the relay actuated the relay time can be set by adjustable resistance setting time 0 5 9 seconds Motor interface output DC5V and keep 0 5 seconds stop 5 seconds then minus vol
