K200-3.3 Multi-function Fingerprint Access Control Board for Door Access Control Work with R502 R502-A R502-AW R503 Fing

Manual Click here to openSpecifications Fingerprint capacity 120 Power supply 4 AA battery or DC5V Stand by mode current less than 5 uA Output DC5 6V 500mAOperation Instructions 1 Press SET button shortly system in administrator register status and blue indicator light flash fast press two times for each fingerprint fingerprint register successfully when hearing music Fingerprint can be registered continuously and it can register 20 pieces administrator fingerprint If no need for adding fingerprint waiting for 6seconds or press the SET button to exit 2 When back to factory default press SET button until hear Di Di Di beep and release the button means initialization operation successful 3 Register User Fingerprint Press the administrator fingerprint until hear the music and blue indicator light flash fast means can add user fingerprint Press two times for each user fingerprint fingerprint register successful when hearing music Fingerprint can be registered continuously it can register 100 pieces user fingerprint 4 Delete User Fingerprint Press the administrator fingerprint when hear the music and blue indicator light flash fast move the finger until hear DiDiDi long deep than all user fingerprints are deleted 5 Mode selection setby the toggle switch a 1 ON 2 ON Output DC5V and keep 0 5 second stop 5 seconds then minusvoltage outputted and keep 0 5 seconds b 1 ON 2 OFF Output DC5V and keep 5 secondc 1 OFF 2 ON Output DC5V and keep 1 secondsd 1
