JumperRC R8 II 16CH RC Receiver Compatible T16 FrSky D16 D8 Mode Support PIX/PX4/APM Flight Controller PWM SBUS Output

JumperRC R8 II 16CH RC Receiver Compatible T16 FrSky D16 D8 Mode Support PIX PX4 APM Flight Controller PWM SBUS OutputNote Jumper R8 has been revised and updated to R8 II It is not much different from the old R8 in use but the difference in appearance OVERVIEW The R8 receiver is the first receiver that can directly transmit the PIXs and PX4 flight control data TX RX to the remote control of the world and can display the flight control data to the remote control through the APM script Since then don t have to install additional converters for getting data back from PIXs PX4 Specifition Item name Jumper R8 II ReceiverNumber of channels 8ch PWM 16ch SBUS RSSI Signal Strength Indication output PWMOperating voltage range 4 0 8 4VOperating current range 100mA 5VEffective distance full distance 2 0km Weight 10gCompatibility FrSky D8 D16 mode Features More channels 1 8 channels from traditional channel output 1 16 channels from SBUS port RSSI output analog voltage output 03 3V Two way full duplex transmission Telemetry With RSSI output analog voltage output 03 3V Pair code method 1 Press the bind button on the receiver red green LED solid on2 On radio side select Frsky D16 protocol T12 T16 Multi Frsky D16 3 When Red LED is flashing binding succeeded 4 After binding withdraw the binding mode and power up the receiver again Green Led turns solid on LED color description The green light is always on the signal is good the green ligh
