JKM Nema 17 Two Phase Hybrid Stepper Motor 37oz-in 34mm 0.4A

Description: JKM Nema 17 Two Phase Hybrid Stepper Motor 37oz-in 34mm 0.4A Specification: Brand: JKM Model: JK42HS34-0404 Motor length: 34mm Diameter of axle: 5mm Voltage: 12V The front shaft length: 24mm Size: 42mm * 42mm * 34mm Holding Torque: 2.8kg.cm 37oz.in Outgoing line: 300mm (Plug is not included) Certification: Certification: CE,ROHS Connection mode: Black:A+,Green: A- Red: B+ Blue: B- Scope: 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting,ect. Genaral Specification: Item Specifications Step Angle 1.8 Temperature Rise 80max Ambient Temperature -20~+50 Insulation Resistance 100 M Min. ,500VDC Dielectric Strength 500VAC for 1minute Shaft Radial Play 0.02Max. (450g-load) Shaft Axial Play 0.08Max. (450g-load) Max. radial force 28N (20mm from the flange) Max. axial force 10N Electrical Specification: Model No. Step Angle Motor Length Rate Voltage Current /Phase Resistance /Phase Inductance /Phase Holding Torque # of Leads Detent Torque Rotor Inertia Mass ( ) (L)mm V A mH g.cm No. g.cm g.cm Kg JK42HS34-0404 1.8 34 12 0.4 30 37 2600 4 200 34 0.22 Package included: 1x Stepper Motor
