JKM NEMA23 1.8°57 Hybrid Stepper Motor Two Phase 56mm 12kg.cm 2.8A Step Motor

Description: JKM NEMA23 1.857 Hybrid Stepper Motor Two Phase 56mm 12kg.cm 2.8A Step Motor Specification: Brand JKM Model 57HS56-2804-13 Motor length 56mm Diameter of axle 8mm The front shaft length 21mm Size 57x57x56mm Holding Torque 12kg.cm Outgoing line 300mm Certification Certification: CE,ROHS Scope 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting,ect. Genaral Specification: Item Specifications Step Angle 1.8 Temperature Rise 80max Ambient Temperature -20~+50 Insulation Resistance 100 MMin. ,500VDC Dielectric Strength 500VAC for 1minute Shaft Radial Play 0.02Max. (450g-load) Shaft Axial Play 0.08Max. (450g-load) Max. radial force 75N (20mm from the flange) Max. axial force 15N Electrical Specifications: Model No. Step Angle Motor Length Rate Voltage /Phase Current /Phase Resistance /Phase Inductance /Phase Holding Torque # of Leads Detent Torque Rotor Inertia Mass ( ) (L)mm V A mH kg.cm No. g.cm g.cm Kg 57HS51-2804 1.8 56 3 2.8 0.9 2.5 12 4 350 280 0.68 Package Included: 1 x Motor More Details:
