JKM NEMA14 1.8°35 Hybrid Stepper Motor Two Phase 34mm 1400g.cm 1A

JKM NEMA14 1.8°35 Hybrid Stepper Motor Two Phase 34mm 1400g.cm 1A
sku: 980605
Shipping from: China
Description: JKM NEMA14 1.835 Hybrid Stepper Motor Two Phase 34mm Motor 1400g.cm 1A Specification: Brand: JKM Model: JK35HY34-1004 Motor length: 34mm Diameter of axle: 5mm The front shaft length: 21mm Size: 35mm x 35mm x 34mm Outgoing line: 300mm (Plug is not included) Certification: CE Scope: 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting, ect. Genaral Specification: Item Specifications Step Angle 1.8 Temperature Rise 80max Ambient Temperature -20~+50 Insulation Resistance 100 MMin. 500VDC Dielectric Strength 500VAC for 1 minute Shaft Radial Play 0.02Max. (450g-load) Shaft Axial Play 0.08Max. (450g-load) Max. radial force 28N (20mm from the flange) Max. axial force 10N Electrical Specification: Model No. Step Angle Motor Length Current /Phase Resistance /Phase Inductance /Phase Holding Torque # of Leads Rotor Inertia Mass ( ) (L)mm A mH g.cm No. g.cm Kg JK35HY34-1004 1.8 34 1.0 2.7 4.3 1400 4 14 0.18 Features: High holding torque at high speed. A stepper motor is an electric motor that is able to create sharp movements. It is widely used in 3D printer, monitor / Medical/Textile/ Packaging Machinery, Stage Lighting,ect. Wiring Diagram: Package Included: 1x Hybrid Stepping Motor More Details:
