JKM NEMA14 1.8°35 Hybrid Stepper Motor Two Phase 28mm Motor 1000g.cm 0.5A

Description: JKM NEMA14 1.835 Hybrid Stepper Motor Two Phase 28mm Motor 1000g.cm 0.5A Specification: Brand: JKM Model: JK35HY28-0504 Motor length: 28mm Diameter of axle: 5mm The front shaft length: 21mm Size: 35mm x 35mm x 28mm Outgoing line: 300mm (Plug is not included) Certification: CE Scope: 3D Printers, Monitor Equipment, Medical Machinery, Textile Machinery, Packaging Machinery, Stage Lighting, ect. Genaral Specification: Item Specifications Step Angle 1.8 Temperature Rise 80max Ambient Temperature -20~+50 Insulation Resistance 100 MMin. 500VDC Dielectric Strength 500VAC for 1 minute Shaft Radial Play 0.02Max. (450g-load) Shaft Axial Play 0.08Max. (450g-load) Max. radial force 28N (20mm from the flange) Max. axial force 10N Electrical Specification: Model No. Step Angle Motor Length Current /Phase Resistance /Phase Inductance /Phase Holding Torque # of Leads Detent Torque Rotor Inertia Mass ( ) (L)mm A mH g.cm No. g.cm g.cm Kg JK35HY28-0504 1.8 28 0.5 20 18 1000 4 80 11 0.14 Features: High holding torque at high speed. A stepper motor is an electric motor that is able to create sharp movements. It is widely used in 3D printer, monitor / Medical/Textile/ Packaging Machinery, Stage Lighting,ect. Wiring Diagram: Package Included: 1x Hybrid Stepping Motor More Details:
