JKM JKD2060AC Two Phase Stepper Motor Driver Digital Stepper Driver 2.0A-6.0A DC 24-80V

Description: JKM JKD2060AC Two Phase Stepper Motor Driver Digital Stepper Driver 2.0A-6.0A DC 24-80V Specification: Type JKD2060AC DC Input Voltage 24V-80V AC Input Voltage 20-60V Output Current 2.0 A - 6.0A Operating Temperature -10 - 45 Storage Temperature -20 - 125 Weight 600g Humidity No condensation, no water droplets Gas Prohibition of combustible gasses and conductive dust Feature: Average current control, two phase sinusoidal current output. Photoelectric isolation signal input and output. With overvoltage undervoltage over-current interphase short circuit protection function. Eight channels subdivison and automatic idle-current reduction. Eight channels output phase current setting. Current Setting: REF Peak SW1 SW2 SW3 2.00A 2.40A on on on 2.57A 3.08A off on on 3.14A 3.77A on off on 3.71A 4.45A off off on 4.28A 5.14A on on off 4.86A 5.83A on on off 5.43A 6.52A on off off 6.00A 7.20A off off off Subdivision Adjustment: SW5 SW6 SW7 SW8 Default on on on on 400 off on on on 800 on off on on 1600 off off on on 3200 on on off on 6400 off on off on 12800 on off off on 25600 off off off on 1000 on on on off 2000 off on on off 4000 on off on off 5000 off off on off 8000 on on off off 10000 off on off off 20000 on off off off 40000 off off off off Signal Indication: Phenomenon Reasons Solution When the indicator light is red The wire of motor shorted out. Cheak or change the wire. The external voltage is over or under the working voltage of the motor driver. Adjust the voltage into proper ranges. Mechanical Dimension: Package Included: 1 x Motor Driver More Details:
