JDY-10 bluetooth 4.0 Module BLE bluetooth Serial Port Module Compatible With CC2541 Slave

Description Model JDY 10 bluetooth 4 0 slave moduleKernel M0Communication interface serial portWorking voltage 1 9 3 6VCommunication distance 100 metersWorking current 90uaSuspen mode 14 uAModule is bluetooth 4 0 slaveJDY 10 transparent transmission module is based on bluetooth 4 0 protocol standard working frequency range is 2 4GHZ range modulation mode is GFSK maximum transmission power is 8db maximum transmission distance is 80 meters low power consumption small size strong signal data transmission Stable and other characteristics Features 1 Support Android IOS mobile phone data penetration2 Support low power consumption standby current can reach several uA 3 Support GPIO and UART peripheral interface4 Support AT command operation5 Can be certified by FCC CE and other standards Product application range 1 bluetooth LED lighting2 Motor adjustment and other products3 Anti lost alarm and other products4 Sports Health Care5 Small appliances6 Automotive Electronics Technical specifications TypeSpecificationsWorking voltage1 93 6VOperating temperature 40 85CMaximum transmit power 8dbmAntennaPCB onboard antennaReceiving sensitivity 92dbm Average currentWake mode90uASuspen mode14 uADeep Sleep mode1uA Factory default configuration Service UUID FFE0Feature UUID FFE1Serial port baud rate 115200bps AT instruction set Users can communicate with the bluetooth chip through the serial port The serial port uses Tx Rx two signal lines and the ba
