JDS6052S Handheld Dual Channel Digital 50M Bandwidth Oscilloscope+5M Function Signal Generator with 2.8-inch Screen

Features 2 8 inch TFT color screenOne click Chinese English Russian Spanish PortugueseCompact body easy to carryLong standby time one 18650 battery can work for 5 hours Specification 1 Oscilloscope Specification Number of channels 2Maximum real time sampling rate CH1 200MSa s for single channel CH1 CH2 100MSa s for single channelBandwidth Single channel 50M dual channel 25MVertical resolution 8 digitsVertical gear 10mV 5V probe x1 100mV 50V probe x10 1 2 5 steppingImpedance 1M 25pFCoupling DC ACDisplay mode Y T X YInput voltage 40V probe x1 400V probe x10 Using a high voltage probe the maximum voltage is determined by the quality of the probeTime base range 12 5ns 5s100ms 5s for scan mode scan Memory depth 3K per channelTrigger mode automatic normal and singleTrigger type rising edge falling edgeAutomatic detection 50Hz 20MHzCursor measurement time voltage manual mode Recordable contrast waveform 2Screenshot function 6 sheets bmp formatMathematical calculations CH1 CH2 CH1 CH2 CH2 CH1Self calibration support 2 Signal Generator Specification Number of channels 1Frequency Zhengxuan wave 1Hz 5MHz Square wave 1Hz 1MHz Positive sawtooth wave 1Hz 1MHz Reverse sawtooth wave 1Hz 1MHz Amplitude 100mV 8VOffset Max 0V 4V Duty cycle 0 100 Battery 18650 rechargeable lithium battery not included Package includes 2 X P6100
