IPC-7100 Video Surveillance Tester Multi-Functional Engineering Tester US Plug

1. 7 inch 1920x1200P full-view IPS screen with clearer and smoother display2. H.265/H.265+ 4K main stream test, 1200W network camera test3. Ultra-fast ONVIF, face/plate recognition, test report, channel name modification4. Upgraded TVI5.0 audio test, TVI/CVI/AHD full 8MP test5. Supports batch activation, IP modification, resetting password, video obstruction alarm, etc. by Hikvision and Dahua test tools6. Added advanced network testing functions such as IP address conflict detection and switch port detection7. Network cable sequence detection, remote/medium/nearest error detection8. Network cable TDR test, open/closed circuit of network cable, quality test9. DC12V/3A, POE48V/25.5W, DC24V/2A, USB5V/2A power supply output10. Supports HDMI signal output, maximum resolution 4K. Can output the current screen display content, and the output resolution can be switched between 1080P/720P11. 4K 30-frame HDMI input, 2K 60-frame VGA input12. Added Internet/local projection, supports remote control and voice intercomParameters1. PoE power output: 48V PoE power output, maximum power 25.5W2. DC 12V power output: output 12V, maximum DC current about 3A, providing temporary working power for the camera3. DC 24V power output: output 24V, maximum DC current about 2A, providing temporary working power for the camera4. USB 5V power output: 5V 2A power output function, can be used as a mobile phone power bank function5. HDMI input: one HDMI input, maximum resolution supports 4K 30 frames4K_3840 x 2160/2K_2560 x 1440p/1920×1080p/1920×1080i/720×480p/720×576p/1280×720p/1024×768p/1280×1024p/1280×900p/1440×900p etc.6. HDMI output: one HDMI output, resolution 1080p/720p7. VGA input: one VGA signal input, can be used as a monitor. Supports the following resolutions:2048 x 1152P 60FPS, 1920 x 1200P 60FPS, 1920 x 1080P 60FPS, 1792 x 1344P 60FPS, 1680 x 1050P 60FPS, 1600 x 1200/900P 60FPS, 1440 x 900P 60FPS, 1360 x 768P 60FPS, 1280 x 1024/960/800/768/720P 60FPS, 1152 x 870P 60FPS, 1024 x 768P 60FPS, 800 x 600P 60FPS, 640 x 480P 60FPS8. Display screen: 7 inch, IPS high-definition full-view capacitive touch screen, resolution 1920 x 12009. Network ports: 10/100/1000M adaptive, RJ45. Dual gigabit Ethernet ports10. WIFI: built-in 2.4G wireless WIFI, maximum rate 150M, receiving images from wireless network cameras, etc.11. WIFI analyzer: built-in WIFI analyzer, can view WIFI information, test WIFI strength, analyze channel occupancy and channel rating, etc.12. External power supply: DC 12V (2A)13. Battery power: built-in 7.4V polymer lithium battery, capacity 7800mAh14. Charging: charging 4.5 hours, once charging can be used normally for 11 hours15. Operation settings: Capacitive touch screen, Chinese, Traditional Chinese, English, Polish, Italian, Korean, Russian, Spanish, French, Japanese, German, Turkish, Serbian, Czech, Portuguese, Vietnamese OSD menu, selectable16. Automatic standby: off/5-30 minutes17. Working temperature: -10 degrees celsius --- +50 degrees celsius18. Working humidity: percent30 - percent9019. Size: about 20.3 x 14.1 x 4.6 cm20. Weight: about 920gPackaging list:- bag x 1- tester x 1- adapter x 1- RS485 control cable x 1- safety rope x 1- BNC cable x 1- power output cable x 1- belt x 1- accessories x 1
