High Precision Digital DDS Dual-channel Multifunction Signal Source Generator Arbitrary Waveform/Pulse Generator Frequency Meter 200MSa/s 12MHz

Features:
Adopts DDS direct digital synthesis technology, can generate precise, stable output signals with higher distortion.
With high quality aluminium alloy shell, and powered by DC 5V, convenient and portable for use.
Can output arbitrary waveform and conventional function waveform(sine/triangle/square/sawtooth wave signal).
All functions are digitally controlled, precise and stable.
2.4(320*240)color display, simultaneously display dual-channel waveform parameters.
The highest output frequency(sine wave) is up to 25MHz, 200MSa/s sampling rate(250MSa/s for 25MHz) and 12 bits vertical resolution(14 bits for 25 MHz).
Completely independent dual-channel output, can work in sync, phase difference is adjustable.
With channel tracking function: when the tracking function is open, the all parameters of both of channel can simultaneously update according to user's configuration.
Two or more machines can realize multi-machine synchronous function with TTL_IO interface.
15 groups of arbitrary wave storage location, the memory depth/group is 2048*12bits(2048*14bits for 25MHz).
High frequency resolution(total range frequency resolution is 1uHz) and high amplitude resolution(Min. is 1mV).
The duty ratio of each channel can be adjusted independently, adjustment resolution can reach 0.1%.
Can scan frequency, amplitude, bias and duty cycle, with linear sweep and logarithmic frequency sweep modes(Max. up to 999.99s).
With pulse train trigger function, three optional trigger modes: manual trigger, inner CH2 trigger and external trigger.
Has a frequency measurement, period measurement, positive and negative pulse width measurement, duty cycle measurements and counting function.
