Hantek DSO5202P Digital Oscilloscope 200MHz Bandwidth 2 Channels 1GSa/s 7inch TFT LCD PC USB Portable Oscilloscope Electrical Tool

Features: 200M bandwidths. 1GSa/s Real Time sample rate. Large (7.0-inch) color display,WVGA(800x480). Record length up to 40K. Trigger mode: edge/pulse width/line selectable video/slop/overtime etc. USB host and device connectivity, standard. Multiple automatic measurements. Four math functions, including FFTs standard. Provides software for PC real-time analysis. Specification: Model DSO5202P DSO5102P DSO5072P Bandwidth 200MHz 100MHz 70MHz Channel 2 Real-Time Sample 1GSa/s Equivalent Sample 25GSa/s Memory Depth 40K Rise Time 1.7ns 3.5ns 5ns Time Base Accuracy 50ppm Time Base Range 2ns/div-40s/div 4ns/div-40s/div Input Impendance 1M VOLTS/DIV Range 2mV/div-5V/div A/D Converter 8 bit Position Range 50V(5V/div) 40V(2V/div-500mV/div) 2V(200mV/div-50mV/div) 400mV(20mV/div-2mV/div) DC Gain Accuracy 3% for Normal or Average acquisition mode, 5V/div to 10mV/div; 4% for Normal or Average acquisition mode, 5mV/div to 2mV/div Bandwidth Limit 200MHz Trigger Types Edge, Video, Pulse, Slope, Over time, Alternative Trigger Source CH1, CH2, EXT, EXT/5, AC Line Math + - x, FFT Cursor Measurement Voltage difference between cursors: V; Time difference between cursors: T; Reciprocal of T in Hertz (1/T); Auto Measurement Frequency, Period, Mean, Pk-Pk, Cycli RMS, Minimum, Maximum, Rise time, Fall Time, +Pulse Width, -Pulse Width, Delay1-2Rise, Delay1-2Fall, +Duty, -Duty, Vbase, Vtop, Vmid, Vamp, Overshoot, Preshoot, Preiod Mean, Preiod RMS, FOVShoot, RPREShoot, BWIDTH, FRF Display 7" TFT 16K Color LCD, 800*480 dots Size 313mm x 108mm x 142mm Weight 2.08KG Standard Probe PP200 x 2 PP150 x 2 PP80 x 2 Package Included: 1 x Hantek DSO5202P Oscilloscope Host 2 x Connecting Lines 1 x USB Cable 1 x Installation CD 1 x Power line 1 x Original box
