Hantek DSO4202C 2 Channel Digital Oscilloscope 1 Channel Arbitrary/Function Waveform Generator From

Features 200M bandwidths 1GSa s Real Time sample rate Large 7 0 inch color display WVGA 800x480 Record length up to 24K Trigger mode edge pulse width line selectable video slop overtime etc USB host and device connectivity standard Multiple automatic measurements Four math functions including FFTs standard Provides software for PC real time analysis Specification ModelDSO4202CSample RateSampling Rate Range 1GSa sEquivalent Sample Rate 25GSa sNormalNormal data onlyPeak DetectHigh frequency and randon glith captureAverageWavefom Average selectable 4 8 16 32 64 128Inputs CouplingAC DC GNDInpits Impendance1MΩ±2 20pF±3pFProbe Attenuation1X 10XSupported Probe Attenuation Factor1X 10X 100X 1000XMaximum Input VoltageCAT I and CAT II 300VRMS 10 CAT III 150VRMS 1 Installation Category II derate at 20dB decade above 100kHz to 13V peak AC at3MHz and above For non sinusoidal waveforms peak value must be lessthan 450V Excursion above 300V should be of less than 100msduration RMS signal level including all DC components removed throughAC coupling must be limited to 300V If these values are exceeded damage to the oscilloscope may occur Sample Rate Range1GS sWaveform Interpolation sin x xRecord Length40KSEC DIV Range2ns div to 40s divSample Rate and±50ppm at over any ≥1ms time interval Delay Time AccuracyPosition Range2ns div to 10ns div 4div x s div to 20ms Vertical Resolution8 bit resolution all channel sampled simultaneouslyPosition Range2mV div to 10V di
