Hantek CC-65 AC/DC Multimeter Current Clamp Meter
Description
Features
AC/DC frequency range: Up to 20 kHz.
Effective Measurement Range: 20mA to 65A DC.
It is a transducer which allows your multimeter to measure current data and enable your oscilloscope to measure the current waveforms.
Its current transducer is composed by permalloy and hall element, which linearly transform the AC or DC current to AC or DC current voltage. And if connect to an oscilloscope by BNC type connector, you're able to observe the current waveforms; If connect to a multimeter by banana type connector, you can obtain the current data.
Specifications
DCA Range
1 mV /10mA ±(1.5%±5mA) 10mA ~ 20A
1mV/100mA ±(2%±20mA) 100mA ~ 40A±(4%±0.3A) 40A ~ 65A
ACA Range
1mV/10mA ±(2%±30mA) 100mA ~ 10A (40Hz ~ 2KHz)±(4%±30mA) 100mA ~ 10A (2KHz ~ 10KHz)±(6%±30mA) 100mA ~ 10A (10KHz ~ 20KHz)±(8%±30mA) 10A ~ 15A (40Hz ~ 20KHz)
1mV/100mA ±(2%±30mA) 200mA ~ 40A (40Hz ~ 1KHz)±(4%±30mA) 200mA ~ 40A (1KHz ~ 2KHz)±(6%±30mA) 200mA ~ 40A (2KHz ~ 5KHz)±(8%±0.3A) 40A ~ 65A (40Hz ~ 20KHz)
Captured Conductor Size 9mm maximum
Low Battery Indicator red LED lighting
Operating Temperature 0℃to 50℃70% R.H.
Storage Temperature -20℃ to +70℃, 80% R.H.
Battery Type 9V DC, NEDA 1604, 6F22,0006P
Battery Life 100 hours typical with alkaline
Output Supplied with coil cable with straight banana plug or BNC plug.
Package Size 20 x 10 x 5 cm
Package Weight 250g
AC/DC frequency range: Up to 20 kHz.
Effective Measurement Range: 20mA to 65A DC.
It is a transducer which allows your multimeter to measure current data and enable your oscilloscope to measure the current waveforms.
Its current transducer is composed by permalloy and hall element, which linearly transform the AC or DC current to AC or DC current voltage. And if connect to an oscilloscope by BNC type connector, you're able to observe the current waveforms; If connect to a multimeter by banana type connector, you can obtain the current data.
Specifications
DCA Range
1 mV /10mA ±(1.5%±5mA) 10mA ~ 20A
1mV/100mA ±(2%±20mA) 100mA ~ 40A±(4%±0.3A) 40A ~ 65A
ACA Range
1mV/10mA ±(2%±30mA) 100mA ~ 10A (40Hz ~ 2KHz)±(4%±30mA) 100mA ~ 10A (2KHz ~ 10KHz)±(6%±30mA) 100mA ~ 10A (10KHz ~ 20KHz)±(8%±30mA) 10A ~ 15A (40Hz ~ 20KHz)
1mV/100mA ±(2%±30mA) 200mA ~ 40A (40Hz ~ 1KHz)±(4%±30mA) 200mA ~ 40A (1KHz ~ 2KHz)±(6%±30mA) 200mA ~ 40A (2KHz ~ 5KHz)±(8%±0.3A) 40A ~ 65A (40Hz ~ 20KHz)
Captured Conductor Size 9mm maximum
Low Battery Indicator red LED lighting
Operating Temperature 0℃to 50℃70% R.H.
Storage Temperature -20℃ to +70℃, 80% R.H.
Battery Type 9V DC, NEDA 1604, 6F22,0006P
Battery Life 100 hours typical with alkaline
Output Supplied with coil cable with straight banana plug or BNC plug.
Package Size 20 x 10 x 5 cm
Package Weight 250g
