Hantek 6202BE USB Oscilloscope 200MHz 2Channels 250MS/s

Features
Excellent industrial design-the same anodised aluminium casing as iPad, which is not only beautiful and tasteful but also greatly enhanced the hardness of aluminum alloy surface, and has good heat resistance and strong wearability.
Standard USBXI TM interface, easily inserts into USBXI TM housing to make up a combination instrument.
USB2.0 interface, no external power source required, easy to use.
Be suitable for notebook computer, product line maintenance,be used easily on business.
High performance, 150MS/s real-time sampling, 50MHz Bandwidth.
Operating System: Windows 7, Windows NT, Windows 2000, Windows XP,VISTA.
23 measurement functions, PASS/FAIL Check, be suitable for technical application.
Waveform average, persistence, intensity,invert,addition, subtraction, multiplication, division,X-Y plot.
Save waveform in the following: text file, jpg/bmp graphic file, MS excel/word file.
FFT.
One computer can connect many DSO, extend channel easily. Labview\\VB\\VC\\Delphi\\C++Builder Second Design instance.
Specifications
Input
Max. Sample Rate 250MSa/s using one channel
Channels 2
Bandwidth 200MHz analog bandwidth
Vertical Resolution 9 bits/channel
Gain Range 100mV-5V/div x 10 probe 1V-500V/div x 100 probe 10V-5KV/div x 1000 probe
Range 8 divisions
Offset Level ± 4 divisions
Coupling AC, DC, GND
Offset Increments 0.02div
Impedance 1M ohm
DC Accuracy ± 3%
Input Protection 35Vpk (DC + PEAK AC ＜ 10KHz, without external attenuation)
Display Mode Y-T, X-Y and Roll
Timebase
Timebase Range 2ns/div-1h/div(1-2-4 sequence)
Acquisition Mode 4ns/div-400ms/div
Range 10 divisions
Buffer Size 10K-1M
Trigger
Type Edge, Pulse
Mode Auto, Normal and Single
Package Size 23 x 12 x 8 cm
Package Weight 2.0kg
