Hantek 6052BE PC-Based USB Digital Dso Storage Oscilloscope 2 Channels

Description : Hantek 6052BE PC-Based USB Digital Dso Storage Oscilloscope 2 Channels Standard USBXITM interface, easyly inserts into USBXITM housing to make up a combination instrument. USB2.0 interface, no external power source required, easy to use. Be suitable for notebook computer, product line maintenance, be used easily on business. Dimensions (mm) : 205(L) x120(W) x35(H) be carried easily. High performance, 150MS/s real-time sampling, 50MHz Bandwidth, Operating System : Windows 7, Windows NT, Windows 2000, Windows XP, VISTA. 23 measurement functions, PASS/FAIL Check, be suitable for technical application. Waveform average, persistence, intensity, invert, addition, subtraction, multiplication, division, X-Y plot. Save waveform in the following : text file, jpg/bmp graphic file, MS excel/word file. FFT One computer can connect many DSO, extend channel easily. LabviewVBVCDelphiC++Builder Second Design instance. Specification : Model Hantek6082BE Hantek6052BE Hantek6022BE SainSmartDDS120 SainSmartDDS140 Channel 2 Channels Bandwidth 80MHz 50MHz 20MHz 20MHz 40MHz Input Impedance 1M 25pF Max. Sample rate 250MSa/s 150MSa/s 48MSa/s 50MSa/s 200MSa/s Coupling AC/DC/GND Vertical resolution 8Bit 8Bit 8Bit Gain range 10mV-5V, 9Steps 5V, 50V, 500V, 5V, 50V, 500V, DC accuracy 3% 3% 3% Timebase range 4ns-1h, 38 Steps Vertical adjustable Yes Input protection Diode clamping X-Y Yes EXT. input Yes No No No Trigger Mode Auto, Normal and Single Trigger Slope +/- Trigger level adjustable Yes Trigger Type Rising edge, falling edge Trigger Source CH1, CH2, EXT CH1, CH2 Pre/Post trigger 0-100% Buffer size 10K-64KB/Channel 1M Sampling selection Yes Waveform Display port/line, waveform average, persistence, intensity Network Open/Close Vertical mode CH1, CH2, Dual, ADD Cursor measurement Yes Math FFT, addition, subtraction, multiplication, division. Cursor Frequency, Voltage Accessories S/W CD, probes, manual, USB cord Package includes : 1 x Professional Hantek 6052BE Oscilloscope 2 x Oscilloscope probe 1 x USB Cable 1 x CD (including manual etc.) Full accessories as picture shows. Details pictures :
