Hantek 4032L Logic Analyzer 32Channels USB Oscilloscope Handheld 2G Memory Depth Osciloscopio Portatil Automotive Oscilloscopes

Hantek 4032L Logic Analyzer 32Channels USB Oscilloscope Handheld 2G Memory Depth Osciloscopio Portatil Automotive Oscilloscopes
hantek
sku: 1376105
$159.99
   Description
Features: The storage depth 2Gbit (DDR2) sampling frequency, 150MHz bandwidth 400MS/s to meet your various needs. Innovative trigger mode and new analysis of measuring means, make you in the measurement of the process more efficient and simple. Hantek4032L can be set in different edge, level, bus, data width trigger mode, easy to use. Innovative data analysis function, makes you more relaxed in the analysis of UART, SPI, I2C and other data. Analysis of two powerful protocol, can ex port CSV, TXT, DOC format, easy to use other tools two analysis. USB2.0 high speed interface, plug and play. Excellent industrial design, similar to desktop oscilloscope interface, easy to use. Specification: The number of channels: 32 The input impedance: 200K(C=10p) Input voltage range: -6V~60V Voltage threshold: -6V~6V The maximum sampling rate: 400MHz The maximum input signal bandwidth: 150MHz The minimum time resolution: 2ns Sampling depth: 64M Sample The storage depth: 2G bits Compatible inputs: TTL, LVTTL, CMOS, LVCOMS, ECL, PECL, EIA Electrostatic protection area: 15KV The host interface: USB Port Working voltage: 4.5V~5.5V Energy consumption: Max. 3.5W Temperature range: Operation: -10 ~60 Storage: -40 ~60 Operating system: WinXP/2000/Win7 Package Included: 1 x 4032L USB Oscilloscope 2 x Transfer Plug 1 x Wire 18 x Measure Clip 1 x Cable Line 1 x Power Adapter Details Pictures:
