Hall Research UHBX-R-PSE HDMI+RS232+IR+PoH UTP Receiver with Power Supply (PSE)

UHBX-R-PSE receiver module when paired with compatible sender ( Hall Research model UHBX-S-PD or UHBX-SC-WP ), can extend HDMI, bi-directional IR, full-duplex RS232 and PoH (power over HDBaseT) over distances of up to 150 meters (500 feet) using a single Cat6 cable. The pair can extend HDMI or single-link DVI video of virtually any resolution, to a maximum distance of 500 ft (150 m). Moreover, these extenders complies with Power-over-HDBaseT or PoH, hence only one end requires a power supply . The end identified as PSE (power sourcing equipment) injects power on to the Cat6 cable and the side identified as PD (powered device) is powered through the Cat6 cable. The PSE side requires connection of an AC adapter that supplies 5v DC, while the PD or WP(wall plate) side is simply powered through the RJ45 connector from the opposite side. Full-duplex RS232 Serial Port extension is provided that can operate at any baud rate to 115,200 (independent of video activity). The extender can also extend IR from one end to the other. IR Detector and IR Emitter cables are sold separately. The IR extension preserves the modulation(carrier) frequency and provides compatibility to virtually any standard. It supports modulation range from 30 KHz to 60 KHz Two user selectable distance modes are available: Standard(default) and Long Reach. If the length of UTP cable is less than 100 meters (330 ft), then STD mode should be used. For the lengths above 330 ft Long Reach (L.R.) mode must be set. Long Reach setting can extend maximum of 1080p@60 Hz, 8-bit color (does not support deep-color or 4Kx2K), RS232, IR and Power up to 500ft (150m).
