HW-XC901 5.8GHZ Microwave Module Radar Sensor Detector Module for Smart Home

Manual Click here to openSpecification Product model HW XC901Working voltage 6 24V Built in 7550 need constant power supply minimum drive 6V300mA ± 100mV Static power consumption 15mAOutput mode 3 3 0V 3 3V with induction 0V without induction the output voltage can be adjusted to 5V at most Transmitting frequency 5 8GHZ±75MHZInduction distance 2 11m adjustable Dip switch 1 2 Delay time 10 1800S adjustable Dip switch 3 4 5 Photosensitive switch 10lux 500lux adjustable Dip switch 6 7 8 Working temperature 20℃ 80℃Dimensions 33 5 25 9mmTrigger mode Repeatable triggerRepeat trigger After the first trigger when the sensing area is triggered again the module delay time will be superimposed again when the first trigger time has not stopped For example the module delay is 10S the induction signal is received again within 10S and then superimposed for 10S the uninterrupted trigger within 10S there will always be an output signal Delay time refers to the duration of high voltage signal output It has nothing to do with the delay the delay is in the order of milliseconds and can be ignored Package included 1 x Radar Sensor Module
