Geekcreit® UNO R3 For Arduino No USB Cable With ESP8266 WiFi Expansion Board ESP-13 Shield

Note: This version of UNO R3 can not compatible with OS system Introduction: ESP8266-Based Serial WiFi Shield for Arduino is designed and developed by Shenzhen Doctors of Intelligence & Technology (SZDOIT). The shield is designed based on esp8266 by Espress if Systems, pin-compatible with Arduino UNO/Mega2560 Development Board. Features: WiFi module is industrial-grade chips ESP8266, which is ESP-12E with metal shield, strong anti-interference ability Shield is pin-compatible with Arduino Uno, Mega2560 and other control board. A voltage converter chip is used to deal with 3.3V (Esp8266) and 5V (Arduino); Dual DIP switches is used for serial ports so that this module shield can be used alone as an Arduino Uno expansion board, and also be used as ESP8266 expansion board; Serial data is transported to WiFi device transparently, and vice versa. Arduino program does not need any configuration; Web Server is developed to configure WiFi parameters and serial port parameters The module shield can be used as an independent ESP8266 development board. for instance downloading the official AT commands firmware NodeMCU open source firmware can be used The module shield also can be used as stand-alone expansion board for Arduino Uno. For more references about Doit serial WiFi module expansion board, driver board information, please refer to: http://www.doit.am Technical Specifications: 802.11 b / g / n wireless standard STA / AP modes support TCP / IP protocol stack One socket Supports standard TCP / UDP Server and Client Supports serial port baud rate configuration: 1200/2400/4800/9600/19200/38400/57600/74800/115200 bps Supports serial data bits: 5/6/7/8 bits Supports serial parity: none Supports serial stop bits: 1/2 bit Pin-compatible with Arduino UNO, Mega Arduino Pin-out 2/3/4/5/6/7/8/9/10/11/12/13 ESP8266 GPIO Pin-out 0/2/4/5/9/10/12/13/14/15/16 / ADC / EN / UART TX / UART RX KEY button: modes configuration Dual-Ports DIP switches: switching Arduino and ESP8266 WiFi operation current: continuous transmission operation: 70mA (200mA MAX) idle mode: Serial WiFi transmission rate: 110-460800bps Temperature: -40 ~ + 125 Humidity: 10%-90% non-condensing Weight: about 20g ESP8266 WiFi Shield More information: User Manual: https://fineshang.gitbooks.io/esp8266-based-serial-wifi-shield-for-arduino-user/content/ Package includes: 1 x Arduino ESP8266 WiFi shield 1 x Arduino Compatible UNO R3 board
