Geekcreit® UNO R3 ATmega16U2 Development Board + 2.4 Inch TFT LCD ILI9341 Touch Display Module For Arduino UNO

UNO R3 board feature: Description: UNO R3 board is 100% compatible with original Arduino, now it has perfect quality and performance . Arduino is an open-source physical computing platform based on a simple i/o board and a development environment that implements theProcessing/Wiring language. Arduino can be used to develop stand-alone interactive objects or can be connected to software on your computer (e.g. Flash, Processing, MaxMSP). The open-source IDE can be downloaded for free (currently for Mac OS X, Windows, and Linux). This is the new Tosduino Uno R3. In addition to all the features of the previous board, the Uno R3 now uses an ATmega16U2 instead of the ATmega8U2 chip. This allows for faster transfer rates, no drivers needed for Linux or Mac (inf file for Windows is needed) and the ability to have the Uno show up as a keyboard, mouse, joystick, etc. Note: The TOSduino Uno R3 requires the Arduino 1.0 drivers folder in order to install properly on some computers. We have tested and confirmed that the R3 can be programmed in older versions of the IDE. However, the first time using the R3 on a new computer, you will need to have Arduino 1.0 installed on that machine. The small chip is ATmega16U2, the 28 pin DIP socket chip is ATmega328-pu. Performance description: Digital I / O digital input / output terminal: 0 to 13. Analog I / O Analog inputs / outputs: 0 to 5. Support ISP download function. Input voltage: No external power supply when connected to the computer USB, external power supply 5V ~ 9V DC voltage input. Output voltage: 5V / 3.3V DC. Using Atmel Atmega328 microprocessor controller. 2.4 inch LCD TFT display Features: Colorful, 18-bit 262,000 different shades 4-wire resistive touchscreen 240 x 320 resolution Spfd5408 controller with built in video RAM buffer 8 bit digital interface, plus 4 control lines Uses digital pins 5-13 and analog 0-3. That means you can use digital pins 2, 3 and analog 4 and 5. Pin 12 is available if not using the micro SD 5V compatible, use with 3.3V or 5V logic Size: 71 x 52 x 7mm File download: Click here to open Package included: 1 x UNO R3 with USB cable 1 x 2.4 inch TFT LCD Shield with touch pen
